Brushless DC BLDC Electric Motor w/ Control - 24V - 600W - 12mm Shaft -
2480 RPMUSD $114.95
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
MAC BMC Brushless DC BLDC Electric Motor - 24V - 600W - 12mm Shaft - 2480 RPM Brushless DC ( BLDC ) motor manufactured by MAC-BMC
Model: 12570-3
Nominal voltage: 24 VDC
No-load speed at 24 VDC: 2480 RPM
Rotation: CCW from shaft end No-load current at 24 VDC: 3 A
Built-in 30A speed controller
Requires 5k Ohm potentiometer (not included) to control speed
Power: 600 Watts
11" long power wires terminated with a 2 pin connector (1 pin male, 1 pin female - 4.5 mm diameter pins) for power and 3 pin female plug for potentiometer speed control
Dimensions (not including shaft): 80.7 mm (3.2") long x 5" diameter
Three hole mounting flange - 6.5 mm (1/4") diameter mounting thru holes located on a 114 mm (4.5") diameter
Shaft dimensions: 24 mm long x 12 mm diameter
Weight: 5 lb. 4 oz. (2380 g)
Returns Accepted for this item if it's within 30 Days
